Automotive Microphone-Exterior MIC

Microphone module consist of microphone capsule, processing circuit, housing with installing structure and cable or connector, which is used for exterior communication and special sound pickup .

Features

  • High SNR MEMS microphone capsule, build in processing circuit, meet the requirements of exterior communication and special sound pickup .

  • Use AEC-Q compliance components and material with excellent temperature and mechanical performance, combined with simulation and design verification to keep the stable reliability performance;

  • Customized interface and error proof design benefit for the assemlby in car maker's factory;

  • IP69 compliance

Performance Parameters

Sensitivity

-3.5dB/-10.5dB/-20dB/-26dB/-37dB

Operating voltage range

 8V±10%

Current consumption

6mA

Output impedance

<200Ω
SNRTyp. 65dBA
THD<1%@94dBSPL
