The OPN8001 Time-of-Fight (ToF) sensor for 3D sensing is one key product of OPNOUS ToF solutions, which offers 100×100 resolution data at frame rates up to 120 frames per second (fps). The device combines ToF sensing with an optimally- designed analog-to-digital converter (ADC) and a versatile, programmable timing gener

Features

Imaging Array

100 × 100 Array
1/6 Optical Format
Pixel Pitch: 16.8 µm
Frame Rate: up to 120 fps
Interface

− Control Interface: CCI(I2C)
− Data Interface: MIPI CSI-2
3.3V Single Power upply
Low Power onsumption with Scalability − <50mW @ 30fps
Low Power onsumption with Scalability − <50mW @ 30fps
On-chip Timing Generator
One System Clock for All Range
Multi-sensor Capability
Micro Lens Availability with Advanced Optical System Solution Capability
Operating Temperature: -20℃ ~ 60℃

OPN8001

Performance Parameters
